LIGHTWEIGHT, COMPACT YET RUGGED

The ZX80 with its lightweight form factor (1.3lbs), is built to fully rugged military standards (MIL-STD-810H) to resist shock, spill, vibration, and a six-foot drop without damage or disruption. It also tolerates temperature extremes of -20°F to 145°F (-29°C to +63°C ) while being IP67-certified and submerged in up to one meter of water for up to 30 minutes. Equipped with a 1,000nit screen and a 16:10 display, the ZX80 excels in crucial tasks requiring optimal device performance and reliability, such as forklift truck operation and UAV control.
getac

DIGITAL TRANSFORMATION ON EDGE-AI

The ZX80 empowers manufacturers, utilities, transport providers, and security services to upgrade and future-proof their mobile assets and operations with AI. Qualcomm neural processor unit (NPU) and 8” ultra-widescreen display makes the ZX80 well-suited to facilities management, unmanned aerial vehicle (UAV) control, real-time analytics, and electronic logging device (ELD) duties, while its sleek yet rugged design fits right in on the move.
getac

BUILT FOR OUTDOOR PERFORMANCE

ZX80’s 8” WUXGA (1900x1200 resolution) widescreen in 16x10 display delivers 1,000 nits of screen brightness, enabling easy display under even the brightest sunlight. Its powerful front speaker, noise-canceling microphones, and best-in-class camera specs (8MP front/16MP rear) make remote guidance and conferencing loud and clear. And with its dual-battery setup, with an additional hot-swappable standard or high-capacity second battery, all-day working is not a problem. Furthermore, an optional digitizer pen enhances precision in data entry and signature capture.
getac

BUILT FOR SEAMLESS COMMUNICATIONS

ZX80’s dual SIM capabilities (one physical SIM + one eSIM) enable easy switching between different carrier networks, with optional 4G LTE or 5G Sub-6 with 4X4 MIMO delivering ultra-broadband cellular (WWAN) data transfer. ZX80 also supports local private networks such as the CBRS band in the US. Wi-Fi 6E and Bluetooth 5.2 round out its short-range wireless capabilities, with optional dedicated GPS (L1/L5) available for precise geolocation even in remote locations.

ANDROID ENTERPRISE RECOMMENDED WITH SOFTWARE UPGRADE SUPPORT

ZX80 is powered by the Android™ 13 operating system and is verified by Google as an Android Enterprise Recommended Rugged Device. Android™ 13 offers a diverse feature set, including application-level language settings, granular control over what information apps can access, and built-in safeguards to protect critical data. ZX80 will also support at least five years of security updates, with at least 3 Android Operating System versions over its lifecycle and various feature enhancements.

DIVERSE CONFIGURATIONS, ACCESSORIES & UPGRADES

ZX80’s battery life can be extended via a high-capacity second battery. NFC or a laser barcode reader can be integrated within the chassis. A 65W USB-C AC adapter and office dock are available for in-office use. A stylus and hand straps can be added for usage on foot. And third-party vehicle dock compatibility enables easy device deployment and usage in a truck, van, or forklift cabin.

Getac ZX80 Features

Asset Management
AI-Ready
Asset Management
12GB RAM / 256GB Storage
Asset Management
4G LTE / 5G Sub-6 4X4 MIMO
Asset Management
Dedicated GPS (L1/L5)
Asset Management
1,000nits Brilliant Display
Asset Management
High-Resolution Front and Rear Cameras

Beyond Expectations.

Our new Bumper-to-Bumper fully rugged warranties go beyond the expected to protect your productivity.

getac

3 Years Warranty

Accidents can take your equipment out of service when you least expect it, especially in a rugged environment, which can cause costly equipment downtime. That is why Getac has introduced accidental damage as standard under our Bumper-to-Bumper warranty, to help minimize your enterprise IT costs. Bumper-to-Bumper is your hassle-free guarantee. That means you can depend on us to have your unit back in service within days.

Standard 3 years Bumper-to-Bumper

For full details of the warranty protection, see the Terms and Conditions.

3 Years Warranty

*Images shown are for reference only. Actual product may vary due to product enhancement.

ZX80 TECHNICAL SPECIFICATIONS

Generation

G1

Operating System

Android™ 13.0

Mobile Computing Platform

Qualcomm® QCS6490, Octa-core 1.9GHz
Max. 2.7GHz

VGA Controller

Qualcomm® Adreno™ 643 GPU

NPU

Qualcomm® Hexagon™ Processor,
up to 13 TOPS with 6th Qualcomm AI Engine

Display

8" Wide Viewing Angle TFT LCD WUXGA (1920 x 1200)
Protection film
1,000 nits LumiBond display with Getac sunlight readable
technology
Capacitive multi-touch screen

Storage & Memory

12GB LPDDR5, 256GB UFS

Keyboard

Power button
3 tablet programmable buttons

Pointing Device

Touchscreen
- Capacitive multi-touch screen
- Optional: Dual mode touchscreen
(multi-touch and digitizer)

Expansion Slot

Optional: 1D/2D imager barcode reader
Optional: NFC ii

I/O Interface

8M pixels webcam x 1
16M pixels auto focus rear camera x 1
Audio in/out combo x 1
USB 3.2 Gen 1 Type-C (with Display port & power delivery) x 1
MicroSD x 1 or Optional: Hybrid SIM card (Nano-SIM, 2FF)
tray with MicroSD x 1 iii
Docking connector x 1
Optional: RF antenna pass-through for GPS,
WWAN and WLAN

Communication Interface

Wi-Fi 6E 802.11ax
Bluetooth (v5.2) iv
Optional: Dual SIM (Nano-SIM 2FF and e-SIM) iii
Optional: 4G LTE mobile broadband iii
Optional: 5G Sub-6 iii
Optional: Dedicate GPS v

Security Feature

Optional: NFC ii

Power

Internal battery (3.86V, typical 4060mAh; min. 3950mAh)
LifeSupport battery swappable technology

Swappable Battery Options:
Battery bay cover (Default)
Battery (3.84V, typical 4990mAh; min. 4870mAh)
High capacity Li-ion battery
(3.84V, typical 9980mAh; min. 9470mAh)

Dimension (W x D x H) & Weight

234 x 149.8 x 17.6mm (9.21" x 5.89" x 0.69")
590g (1.3lbs) vi

Rugged Feature

MIL-STD-810H certified
IP67 certified
Vibration & 6ft (1.8m) drop resistant vii
Optional: ANSI/UL 121201, CSA C22.2 NO. 213
(Class I, Division 2, Groups A, B, C, D) viii

Environmental Specification

Temperature ix:
- Operating: -29˚C to 63°C / -20°F to 145°F
- Storage: -51°C to 71°C / -60°F to 160°F
Humidity:
- 95% RH, non-condensing

Pre-installed Software

Getac Camera
Getac Input Method
Getac Driving Safety Utility (trial version)
Getac settings and Google applications (Search, Chrome,
Gmail, Maps, YouTube, Play, Drive, YouTube music,
Google TV, Duo and photos)
Getac Log Tool
Getac Diagnostic Tool
Getac Monitoring (trial version) agent/SDK
Getac Management (trial version) agent/SDK

Optional software

Getac Driving Safety Utility
Getac Monitoring
Getac Management
Getac OEMConfig

Accessories

Optional:
Carry bag
Battery (3.84V, typical 4990mAh; min. 4870mAh)
High capacity Li-ion battery
(3.84V, typical 9980mAh; min. 9470mAh)
DC-DC vehicle adapter (65W, 11-32VDC)
Multi-Bay charger (Dual-Bay)
Multi-Bay charger (Eight-Bay)
Digitizer pen with tether
Capacitive stylus with tether
Protection film
Hand strap with stylus holder
Rotating hand strap with kickstand
Shoulder strap (2-point)
Vehicle cradle x
Vehicle dock x
Office dock
65W USB-C AC Adapter

Bumper-to-Bumper Warranty

Accidents can take your equipment out of service
when you least expect it, especially in a rugged
environment, which can cause costly equipment
downtime.
That is why Getac has introduced accidental
damage as standard under our
Bumper-to-Bumper warranty, to help minimize
your enterprise IT costs.
Bumper-to-Bumper is your hassle-free guarantee.
That means you can depend on us to have your
unit back in service within days.

Standard
3 years Bumper-to-Bumper

    • Certified by June 2024. Android enterprise recommended rugged devices deliver a consistent set of features verified by Google with an elevated device baseline, increased security standards and enterprise-focused features and behaviors to meet the needs of users. Google and Android are trademarks of Google LLC.
    • 13.56MHz contactless NFC (ISO 15693, 14443 A/B, Mifare and FeliCa™ compliant).
    • One physical SIM card slot and one eSIM. Network service may vary depending on local telecommunication providers.
    • Bluetooth performance and connectable distance may be subject to interference with the environments and performance on client devices, users may be able to reduce effects of interference by minimizing the number of active Bluetooth wireless devices that is operating in the area.
    • Support GPS, GLONASS, Galileo and BeiDou.
    • Weight and dimensions vary from configurations and optional accessories.
    • Drop test results vary from configurations and optional accessories.
    • Available with limited configurations and environment conditions.
    • Tested by an independent third-party test lab following MIL-STD-810H.
    • Gamber-Johnson vehicle dock and cradle are e-mark certified.

Information provided herewith is for reference only, available specification shall be subjected to quotation by request.

ZX80 ACCESSORIES

CARRY BAG
MULTI-BAY BATTERY CHARGER EIGHT BAY
EXTERNAL DUAL BAY MAIN BATTERY CHARGER
DIGITIZER PEN WITH TETHER
GETAC DS100 USB-C DOCKING STATION
SHOULDER STRAP 2-POINT
OFFICE DOCK
ROTATING HAND STRAP & KICKSTAND
HAND STRAP WITH STYLUS HOLDER
HIGH-CAPACITY BATTERY 9980MAH
STANDARD BATTERY 4990MAH
SCREEN PROTECTION FILM (AG)
CAPACITIVE HARD TIP STYLUS & TETHER
65W USB-C AC ADAPTER
Vehicle Dock (Gamber-Johnson)
Vehicle Dock / Cradle (RAM Mounts)

Getac Accessory Warranty - 1 year
Third-party Partner Accessory Warranty - 3 years
